Produktinformationen "PACLED 64"
Features:
64 LED channels with 256 brightness levels for full RGB color mixing
NEW FEATURE! Can be set to flash any or all LEDs at one of 3 rates, without PC control.
Can be used with single-color or RGB LEDs (RGB use 3 channels)
Constant current negates the need for resistors for each LED
Can be used with LEDs with inbuilt resistors if required
128-command flash storage for “attract-mode” sequences which run immediately on power-up with no PC present
Supports single-command fades with preset speed on-board. Multiple fades can overlap
Comes with power cable for plugging into a PC disk drive power connector, and USB cable
User-assigned IDs allow multiple boards to be connected
Extensive software support including test application, Software Development kit for
adding support to your own programs, and LedBlinky third-party software Compact modular connectivity. Our Ultralux RGB pushbuttons simply plug in. Other harnesses and connectors available.
Kit Contents:
PacLED64 Board.
USB Cable
Power cable for connection to PC HDD power
2 x 48-way empty connector housings. Wires with crimp contacts (ordered separately if required) push into these.
64 LED channels with 256 brightness levels for full RGB color mixing
NEW FEATURE! Can be set to flash any or all LEDs at one of 3 rates, without PC control.
Can be used with single-color or RGB LEDs (RGB use 3 channels)
Constant current negates the need for resistors for each LED
Can be used with LEDs with inbuilt resistors if required
128-command flash storage for “attract-mode” sequences which run immediately on power-up with no PC present
Supports single-command fades with preset speed on-board. Multiple fades can overlap
Comes with power cable for plugging into a PC disk drive power connector, and USB cable
User-assigned IDs allow multiple boards to be connected
Extensive software support including test application, Software Development kit for
adding support to your own programs, and LedBlinky third-party software Compact modular connectivity. Our Ultralux RGB pushbuttons simply plug in. Other harnesses and connectors available.
Kit Contents:
PacLED64 Board.
USB Cable
Power cable for connection to PC HDD power
2 x 48-way empty connector housings. Wires with crimp contacts (ordered separately if required) push into these.
| Typ: | Sonstiges |
|---|
